General Information

Manufacturer: Linksys
Manufacturer Part Number: EA9500
Manufacturer Website Address:
Brand Name: Linksys
Product Line: Max-Stream
Product Series: EA
Product Model: EA9500
Product Name: EA9500 Max-Stream AC5400 Tri-Band Wi-Fi Router
Marketing Information: Designed as a dual-purpose office and entertainment router, this powerful unit features MU-MIMO technology to treat all of your devices as if each has its own dedicated router and deliver incredibly fast speeds to multiple users on multiple devices. With streamless roaming, your enabled wireless devices will automatically switch to the strongest Wi-Fi signal so you won't have to manually connect to the router or range extender (sold separately) when you move from room to room. You can quickly download large files thanks to the 1.4 GHz dual-core processor that delivers the performance necessary for seamless videoconferencing and fast file transfers. Three independent Wi-Fi bands deliver extremely fast combined speeds of up to 5.3 Gbps to eliminate any lag or buffering. Eight adjustable antennas deliver optimal coverage and maximum signal strength throughout your entire office ensuring complete access throughout your office.
Packaged Quantity: 1
Product Type: Wireless Router

Wireless Specifications

Broadband Transmission Technology: Ethernet
Wireless LAN Standard: IEEE 802.11ac
ISM Band: Yes
UNII Band: Yes
ISM Maximum Frequency: 2.40 GHz
UNII Maximum Frequency: 5 GHz
Number of External Antennas: 8
Total Wireless Transmission Speed: 678.40 MB/s

Interfaces/Ports

Number of Network (RJ-45) Ports: 8
USB: Yes
PoE (RJ-45) Port: No
Number of Broadband (RJ-45) Ports: 1

Network & Communication

Ethernet Technology: Gigabit Ethernet

Physical Characteristics

Form Factor: Desktop
Height: 2.6"
Width: 12.5"
Depth: 10.4"
Weight (Approximate): 3.81 lb

Miscellaneous

Package Contents:

• EA9500 Max-Stream AC5400 Tri-Band Wi-Fi Router
• Quick Start Guide
• 8 x Antennas
• Ethernet Cable
• Power Adapter
• CD-ROM with Documentation

Recycled: No
Assembly Required: No
Country of Origin: China

Warranty

Limited Warranty: 3 Year
